Product Overview
Here are the full specifications of Intel Xeon E5-2680 v2 — the CPU about:
🔑 Key Specifications
| Attribute | Detail |
|---|---|
| Cores / Threads | 10 physical cores / 20 threads |
| Base Clock | 2.80 GHz |
| Max Turbo (Boost) Clock | Up to 3.60 GHz |
| Architecture / Codename | “Ivy Bridge-EP”, part of Xeon E5 v2 family |
| Lithography / Process Node | 22 nm |
| Socket / Package | FCLGA2011 (LGA2011) |
| Max CPUs per System (SMP) | Supports dual-CPU configuration (2 CPUs) |
🎗 Memory & I/O Support
-
Memory Type: DDR3 (DDR3-800 / 1066 / 1333 / 1600 / 1866)
-
ECC Support: Yes (supports ECC memory)
-
Memory Channels: Quad-channel (4 channels)
-
Maximum Supported Memory (theoretical): up to ~ 768 GB (depending on board & configuration)
-
Memory Bandwidth: ~ 59.7 GB/s
-
PCI-Express Support: PCIe 3.0, up to 40 lanes
🖥 Features & Technologies
The CPU supports a broad set of modern server/workstation technologies:
-
Hyper-Threading (so 10 cores → 20 threads)
-
Intel® Turbo Boost Technology 2.0
-
Intel 64-bit, AES-NI, AVX (vector instructions), VT-x (virtualization), VT-d (I/O virtualization), Execute Disable Bit, Enhanced SpeedStep, Demand-Based Switching, Thermal Monitoring, and more.
-
Supports dual-CPU (SMP) systems, making it suitable for servers/workstations.
🔋Power & Thermal
-
TDP (Thermal Design Power): 115 W
-
QPI / Interconnect: 8 GT/s QPI links / 2 links (for multi-CPU communication)
Compatible Devices : Dell Poweredge R420, Dell Poweredge R620, Dell Poweredge R720
